12" Tee Cap

Article number: ISTC12

InnoFlue Tee Cap provide a versatile solution designed to optimize your exhaust system's performance and maintain its integrity. Crafted with precision and durability, InnoFlue Tee Caps ensure a secure seal and prevents leaks at the junction of exhaust system tees. Evaluated to UL1738 and ULCS636 by ICC, InnoFlue Tee Caps are a part of InnoFlue's Condensate Management Portfolio.

  • Forms airtight seal and protects from leaks at any open connection in vent system
  • Lightweight and durable
  • Evaluated to UL1738 and ULCS636 by ICC.
  • Installs quickly & easily without glues, primers, or solvents.
  • Rated to 230°F (110°C).
View all specifications

All media

ISTC12

Specifications

General

Product Name
12" Tee Cap
Trade name
InnoFlue
GTIN
0815010012819
Part number
250407703370

Technical

Color
Gray
Material
PPs
System type
Single wall

Dimensions

Length gross
337.82 mm / 13.3 inch
Height
350.52 mm / 13.8 inch
Diameter flue pipe
315 mm / 12 inch
Width
350.52 mm / 13.8 inch
Net weight
3.22 kg / 7.1 lbs

Logistical

Intrastat
3917400090
Base unit packaging
Unpacked
Packaging / Trade length
337.82 mm / 13.3 inch
Packaging / Trade height
350.52 mm / 13.8 inch
Number per packaging
1
Gross weight
3.221 kg / 7.1 lbs
Packaging / Trade width
350.52 mm / 13.8 inch

Performance

Temperature resistance (max.)
120 °C

Certification

Certificates (US/CAN)
UL 1738 – ICC-ES / ULC S636 – ICC-ES
